Specialty:
1. Up to 600 knots/min high knotting speed with rotary stepless speed control
2. No equipment adjustment needed for 2–160 warp yarns
3. Powerful high-speed DC drive motor for stable operation
4. Built-in 1–6 times auto stop & slow stop safety protection
5. Compatible with cotton, glass fiber, nylon, aramid and blended yarns
6. Designed for off-machine lease-free warp tying of movable frame looms
Tel:+86-13057251795
Mail: sales006@wxzhongyin.com
Mian Purpose:
For lease-free warp tying of staple & long yarns outside movable frame looms, cut loom downtime and boost tying efficiency.
Features:
High knotting speed up to 600 knots/min with rotary stepless speed regulation, matched with high-speed DC motor. It covers wide yarn range without extra adjustment, equipped with auto stop and slow stop protection, suitable for multiple types of yarns.
Specification Table:
| Parameter Item | Value |
|---|---|
| Model | ZYTT-198 Automatic Without Lease Knotting Machine |
| Max Knotting Speed | 600 knots/min |
| Working Mode | External warp of movable frame loom |
| Power Configuration | electric, 100W*36V*5A*180000 revolutions/min, DC motor, manual, a small amount of test results |
| Speed Control | Rotary stepless speed regulation |
| Knitting Yarn Range | 2S-200S, 20D-3000D |
| Working Width | 1m-4m, customizable |
| Applicable Yarns | Pure cotton yarn, blended yarn, glass fiber yarn, nylon yarn, aromatic polyamide fiber yarn |
| Yarn Count Coverage | 2–160 yarns, no extra adjustment required |
| Protection Function | 1–6 automatic stops & 1–6 automatic slow stops |
