Product Description
Fabric dyeing machine is a mechanical equipment used in the textile industry to dye fabrics and textiles. These machines are designed to apply color efficiently and evenly to various types of fabrics, such as cotton, silk, wool and synthetic materials.
Tel:+86-13057251795
Mail: sales006@wxzhongyin.com
Feature
The main purpose of a fabric dyeing machine is to ensure that the dye is evenly distributed throughout the fabric, resulting in vibrant and consistent coloration. These machines use a combination of water, dyes, and chemicals to achieve the desired color and shade. They are equipped with tanks or barrels that hold a dye solution, and the fabric is dipped into or passed through these tanks to absorb the dye.
These machines are equipped with temperature and pressure control systems to maintain optimal dyeing conditions. They also have features such as a stirring mechanism that prevents fabrics from wrinkling and tangling during the dyeing process. Some advanced models may even have computer controls that allow precise control of dyeing parameters for consistent and repeatable dyeing results.
Advantage
Product specifications
| ITEM MODEL | KC-1 | KC-2 | KC-3 | KC-4 | ||
| MAX.TEMPERATURE | ℃ | 140 | 140 | 140 | 140 | |
| MAX.PRESSURE | Kg/c㎡ | 4 | 4 | 4 | 4 | |
| DESIGN CAPACITY | Kg | 300 | 600 | 900 | 1200 | |
| MAIN PUMP POWER | KW | 18.5/22 | 30/37 | 45/55 | 75 | |
| FABRIC SPEED | M/min | 150-600 | 150-600 | 150-600 | 150-600 | |
| DIMENSION (MM) | LENGTH | L1 | 9588 | 9588 | 9588 | 9588 |
| L2 | 10876 | 10876 | 10876 | 10876 | ||
| WIDTH | W | 1680 | 2927 | 3650 | 5200 | |
| HEIGHT | H1 | 2953 | 2953 | 2953 | 2953 | |
